Type of configuration | with engine |
Producer | FLUIMAC |
Pump capacity, cu.m/hour | 6 |
Feed height, m | 8 |
Material | PVDF |
Serial number of the pump | DRAGON |
Country of Origin | Italy |
Input pipe diameter | G1 1/2 |
Output pipe diameter | G1 |
Power capacity, kW | 0,37 |
Power supply | 3х380 V, 50 Hz |
Explosion protection | Yes |
PumpType | console |
Drive Type | electric |
Installation Type | horizontal |
Max.flow rate, m3/h | 6 |
Max. head, m | 8 |
Max.viscosity, cPs | 100 |
Model | DR 006 |
Seal | Mechanical Seal, SiC/C/FPM/SS304 (PTFE bellows) |
Impeller material | PVDF |
Housing material | PVDF |
Material of O-ring | VITON |
Operating temperature | -20°C + 90°C |
Availability of spare parts | yes |
Warranty, months | 12 |
Type of configuration | with engine |
Producer | FLUIMAC |
Pump capacity, cu.m/hour | 6 |
Feed height, m | 8 |
Material | PVDF |
Serial number of the pump | DRAGON |
Country of Origin | Italy |
Input pipe diameter | G1 1/2 |
Output pipe diameter | G1 |
Power capacity, kW | 0,37 |
Power supply | 3х380 V, 50 Hz |
Explosion protection | Yes |
PumpType | console |
Drive Type | electric |
Installation Type | horizontal |
Max.flow rate, m3/h | 6 |
Max. head, m | 8 |
Max.viscosity, cPs | 100 |
Model | DR 006 |
Seal | Mechanical Seal, SiC/C/FPM/SS304 (PTFE bellows) |
Impeller material | PVDF |
Housing material | PVDF |
Material of O-ring | VITON |
Operating temperature | -20°C + 90°C |
Availability of spare parts | yes |
Warranty, months | 12 |
Download instructions, catalog for Хімічний відцентровий насос FLUIMAC DRAGON 6 PVDF, 0,37 кВт, 380В, Ex
